Presonus Studio 24C USB-C Audio Interface w/Studio One Artist

SKU: PRE-STUDIO-24C
IN STOCK
Online: YES
In-store: Yes

$249.00

 In Store Pick Up - Osborne Park, WA

Studio 24C USB-C interface with 2 x XMAX-L preamps

Price Match Request - Found this product at a lower price?
- +
Compare

Input/Output
Simultaneous I/O up to 2 inputs/2 outputs
2 mic/instrument/line inputs with XMAX-L mic preamps
2 balanced ¼” TRS main outputs
1 stereo headphone output
MIDI In/Out
1 USB-C™ compatible 2.0 port
USB-C™ to USB-C™ and USB-C™ to USB-A cables included for compatibility with most computers
Meters, Controls, and Features
Mixer knob for low-latency direct input monitoring
Front-panel level controls for main outputs
+48V phantom power for condenser microphones (global)
4 ladder-style LED level meters (2 input, 2 main output)
Integrated Software
Studio One Artist®
Studio Magic Plug-in Suite
Digital
USB-C™ compatible port (USB 2.0)
24-bit resolution
44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
Physical
Road-rugged construction with all-metal chassis and metal knobs
USB bus-powered

Computer system requirements:
Below are the minimum computer-system requirements.

Mac
macOS® 10.11 or higher (64-bit only)
Intel® i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
Windows
Windows® 7 x64 SP1 + platform update, Windows 8.1 x64, Windows 10 x64
Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
Mac and Windows Systems
USB-C™ or USB-A 2.0 port compatiblity
32 GB hard disk space
PreSonus Universal Control 2.0 or higher
Monitor with 1366×768 resolution (high-dpi monitor recommended)
Multitouch-enabled monitor required for touch operation
VST Compatible Logo ASIO Compatible Logo

VST is a registered trademark of Steinberg Media Technologies GmbH
ASIO is a trademark and software of Steinberg Media Technologies GmbH
All other trademarks are property of their respective holders

Technical Specifications
General
Sample Rates 44.1, 48, 88.2, 96, 176.4, or 192 kHz
Converter Resolution 24 bit
ADC Converter Dynamic Range 108 dB
DAC Converter Dynamic Range 108 dB
Microphone Inputs
Maximum Level +10 dBu (±0.5 dBu, min gain)
Gain Range 50 dB
Frequency Response 20 Hz – 20 kHz (±0.3 dBu, unity gain, unwtd)
Dynamic Range 106 dB (A-wtd, min gain)
THD + N 0.004% (1 kHz, -1 dBFS, min gain)
EIN -126 dBu (A-weighted, 150?, max gain)
Input Impedance 1.4 k?
Phantom Power +48 VDC (10 mA total)
Instrument Inputs
Maximum Level +19 dBu (min gain)
Gain Range 50 dB
Frequency Response 20 Hz – 20 kHz (±0.1 dBu, unity gain, unwtd)
Dynamic Range 105 dB (A-wtd, unity gain)
THD + N 0.002% (1 kHz, min gain)
Input Impedance 750 k?
Main Outputs
Type
¼” TRS, Female

Maximum Level +10 dBu (1 kHz, unity gain, balanced)
Frequency Response 20 Hz – 20 kHz (±0.3 dBu, unity gain, unwtd)
Dynamic Range 104 dB (unity gain, unwtd)
THD + N 0.001% ( 1 kHz, -1 dBFS, unity gain)
Headphone Outputs
Maximum Power 47 mW / channel @ 56?
Frequency Response 20 Hz – 20 kHz (±0.5 dBu, unity gain, unwtd)
Dynamic Range 83 dB (A-wtd, 56? load)
THD + N 0.01% (1 kHz, 0 dBFS, loaded)
Impedance Working Range 32? to 300?
Physical
Height 1.75″ (44 mm)
Width 7″ (180 mm)
Depth 5.5″ (144 mm)
Weight 2 lbs. (0.9 kg)

Brand

PRESONUS

Weight 1 kg
Dimensions 14.4 × 18 × 4.4 cm
