Presonus Studio 1824C USB-C Audio Interface w/Studio One Artist

SKU: PRE-STUDIO-1824C
Ships in 24 hours
Online: YES
In-store: Yes

$799.00

 In Store Pick Up - Osborne Park, WA | NOT INSTANT (4 hours processing)

Studio 1824C USB-C interface with 8 x XMAX class A preamps

- +
Compare

Input/Output
Up to 18 inputs/20 outputs simultaneously (8×8 at 192 kHz)
2 mic/instrument/line inputs with XMAX Class A mic preamps
6 mic/line inputs with XMAX Class A mic preamps
8 channels of ADAT Optical I/O (4 channels at 96 kHz)
2 balanced ¼” TRS main outputs
DC coupled for sending control voltages
8 balanced ¼” TRS line outputs for monitor mixing
DC coupled for sending control voltages
2 stereo headphone outputs with individual level controls
MIDI In/Out
Stereo S/PDIF digital I/O
1 USB-C™ compatible 2.0 port
USB-C™ to USB-C™ and USB-C™ to USB-A cables included for compatibility with most computers
BNC word clock output
Integrated Software
Studio One® Artist for Mac® and Windows®
UC Surface control software for Mac, Windows, iPad®, and Android™
Studio Magic Plug-in Suite
Meters, Controls, and Features
18×8 onboard DSP monitor mixer
Front-panel level controls for main outputs
Mono and Mute buttons for the main outputs
True +48V phantom power for condenser microphones (global)
10 ladder-style 8-LED level meters (8 input, 2 main output)
Digital
USB-C™ compatible port (USB 2.0)
24-bit resolution
44.1, 48, 88.2, 96, 176.4, and 192 kHz sampling rates
Physical
1U rack-mountable
Road-rugged construction with all-metal chassis and metal knobs

Computer system requirements:
Below are the minimum computer-system requirements.

Mac
macOS® 10.11 or higher (64-bit only)
Intel® i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
Windows
Windows® 7 x64 SP1 + platform update, Windows 8.1 x64, Windows 10 x64
Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
Mac and Windows Systems
USB-C™ or USB-A 2.0 port compatiblity
32 GB hard disk space
PreSonus Universal Control 2.0 or higher
Monitor with 1366×768 resolution (high-dpi monitor recommended)
Multitouch-enabled monitor required for touch operation
iOS
iOS 10 or later
iPad Pro, iPad Air 2, iPad Air, iPad mini 4, iPad mini with Retina display, iPad (4th generation)?
Android
Android™ 5.0 (Lollipop) or later
Android tablet (8-inch) with 1024×768 resolution (UC Surface)
VST Compatible Logo ASIO Compatible Logo

VST is a registered trademark of Steinberg Media Technologies GmbH
ASIO is a trademark and software of Steinberg Media Technologies GmbH
All other trademarks are property of their respective holders

Technical Specifications
General
Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
Converter Resolution 24-bit
Converter Dynamic Range 114 dB
Converter Dynamic Range 114 dB
Microphone Inputs
Maximum Level +16 dBu, min gain
Gain Range 80 dB
Frequency Response 20 Hz – 20 kHz (unity gain)
Dynamic Range 110 dB (A-wtd, min gain)
THD + N 0.005% (1 kHz, 0dBu, unity gain)
EIN -128 dBu (A-wtd, 20 kHz BW, Rs=150?, max gain)
Input Impedance 1400?
Phantom Power 48V (>10 mA per channel)
Line Inputs
Maximum Level +21 dBu (balanced, min gain)
Gain Range 40 dB
Frequency Response 20 Hz-20 kHz (unity gain)
Dynamic Range 112 dB (A-wtd, min gain)
THD + N 0.005% (1 kHz, +18 dBu, min gain)
Input Impedance 10 k?
Instrument Inputs
Maximum Level +15 dBu (unbalanced, min gain)
Gain Range 80 dB
Frequency Response 20 Hz – 20 kHz (min gain)
Dynamic Range 112 dB (A-wtd, min gain)
THD + N 0.020% (1 kHz, +10 dBu, min gain)
Input Impedance 1M ?
Main Outputs
Type ¼” TRS female, DC Coupled
Maximum Level +18 dBu, balanced
Frequency Response 20Hz – 20kHz (unity gain)
Dynamic Range 108 dB (A-wtd, unity gain)
THD + N 0.004% (1 kHz, -1 dBFS, unity gain)
Line Outputs
Type ¼” TRS female, DC coupled
Maximum Level +18 dBu, balanced
Frequency Response 20 Hz – 20 kHz
Dynamic Range 108 dB (A-wtd, -60 dBFS)
THD + N 0.004% (1 kHz, -1 dBFS, unity gain)
Headphone Outputs
Maximum Power 150 mW/channel (60? load)
Frequency Response 20 Hz – 20 kHz (unity gain)
Dynamic Range 103 dB (A-weighted, 1 kHz, unity gain)
THD + N 0.250% (1 kHz, 150 mW, unity gain)
Impedance Working Range 32? to 600?
Physical
Height 1.75″ (44 mm)
Width 19″ (483 mm)
Depth 5.5″ (140 mm)
Weight 4.8 lbs (2.2 kg)

Brand

PRESONUS

Weight 2 kg
Dimensions 14 × 48.3 × 4.4 cm
